PYF系列復合圓錐破碎機

丁寶勤 13906276368(技術)

電話：0513-88400999 傳真：0513-88400998 郵箱：jszk@vip.163.com

復合圓錐破碎機

PYF系列復合圓錐破碎機通常應用在二級破碎、三級破碎，采用了破碎平率和偏心距，使得所要破碎的物料細碎程度更高，破碎產能與同類機型相比具有更高產量，且每種規格的破碎機腔型多，用戶可根據不同的需要，選擇不同的腔型，廣泛應用于冶金工業、建材工業、筑路工業、化學工業等領域中，適用于破碎中等和中等以上硬度的各種礦石和巖石。

PYF series compound cone crusher is usually used in the secondary and tertiary crushing. It adopts the best combination of crushing frequency and eccentricity, so that a higher degree of fine crushing can be obtained for the materials to be crushed. Compared with similar models, it has higher crushing capacity. There are many types of crusher cavity. The user can choose different types of cavity according to different needs. The crusher is widely used in different industries such as metallurgy, building materials, road construction, chemistry and other fields. It is suitable for crushing ores and rocks of medium or higher-level hardness.

產品特點Product features

■破碎力大，粒形好，效率高，處理量高

■在中、大規格破碎機中，采用液壓清腔系統，減少了停機時間

■腔型多樣化，滿足用戶不同的需求

■采用潤滑脂密封，避免給水及排水系統易堵塞的弊病及水油易混合的缺陷

■采用彈簧保險系統，使異物、鐵塊通過破碎腔而不損壞破碎機

■調整排礦口方便

Large crushing force.good particle shape,high efficiency,high handing capacity

In the medium and large-sized crushers,the use of hydraulic cavity clearing system can reduce downtime

The diversification of cavity type can meet the need of different users

The use of grease seal can avoid the easy blocking of the water supply and drainage and easy mixing of water and oil

The of spring protection system can mark the foreign body and iron getting through the crushing The adjustment of the discharge port is convenient

技術參數表ITechnical Date

規格	型號	腔型	排料口調整范圍(mm )	給料粒度上限(mm )	處理能力(t/h)	重量(kg )	功率(kw )
	PYFB-0910	STD F	9-22	85	45-91	12367
	PYFB-0917	STDC	13-38	150	59-163	12221
PYF900	PYFB-0918	STD EC	25-38	150	118-163	12220	75
PYF900	PYFB-0904	SH F	3-13	35	27-90	13164	75
	PYFB-0906	SH M	3-16	51	27-100	13321
	PYFB-0907	SH C	6-19	65	59-127	13316
	PYFB-1313	STD F	13-31	115	109-181	22476
	PYFB-1321	STD M	16—38	178	132-253	22167
	PYFB-1324	STDC	19-51	205	172-349	22120
PYF1300	PYFB-1325	STD EC	25-51	220	236-358	22125	160
PYF1300	PYFD-1306	SH F	3-16	54	36-163	21703	160
	PYFD-1308	SH M	6-16	78	82-163	21675
	PYFD-1310	SH C	8-25	89	109-227	21789
	PYFD-1313	SH EC	16-25	113	209-236	21821
	PYFB-1620	STD F	16-38	178	181-327	41460
	PYFB-1624	STD M	22-51	205	258-417	41087
	PYFB-1626	STDC	25-64	228	299-635	40843
PYF1600	PYFB-1636	STD EC	38-64	313	431-630	40674	250
PYF1600	PYFD-1607	SH F	5-13	60	90-209	40734	250
	PYFD-1608	SH M	6-19	76	136-281	40614
	PYFD-1613	SH C	10-25	113	190-336	40531
	PYFD-1614	SH EC	13-25	129	253-336	40374
	PYFB-2127	STD F	19-38	236	554-1034	94263
	PYFB-2133	STD M	25-51	284	862-1424	94519
	PYFB-2136	STDC	31-64	314	1125-1814	94471
PYF2100	PYFB-2146	STD EC	38-64	391	1252-1941	92524	400
PYF2100	PYFD-2110	SH F	5-16	89	218-463	95430	400
	PYFD-2113	SH M	10-19	113	404-580	95242
	PYFD-2117	SH C	13-32	151	517-680	95082
	PYFD-2120	SH EC	16-35	172	580-744	93808

STD F	標準細型	SH F	短頭細型
STD M	標準中型	SH M	短頭中型
STDC	標準粗型	SHC	短頭粗型
STD EC	標準特粗型	SH EC	短頭特粗型
